CP85
CHART PROJECTOR (Cool light)
CP85 Auto Projector(cool lights) can provide 30 types of clear icons with different functions, and can program icon groups per specific needs. It can produce more precise measurement results in shorter time by remote controller and fast toggling icon, applying red/green & polarized icon test sheet, binocular eyesight and binocular balance.
Using cool lights
This kind of light can be used long time, the clearness of its natural light is very high. Moreover, this light is energy-saving.
Customer Programmable
Icons can be displayed in predefined sequence by programming.
Display Single Icon
Display single icon by multi-function mask plate.
Tilted Placement
Perfect image position can be obtained by adjusting the horizontal axis of projector.
Specification:
Projection distance: |
1.5m ~ 6m |
Projection magnification: |
30 x (at 5m) |
Projection size: |
330mm(W) x270mm(H) (at 5m) |
Chart : |
30 different pattern |
Speed of chart conversion: |
One chart per 0.03s |
Mask: |
1 open, 5 horizontal lines,8 vertical lines, 21 single letters, 1 red/green |
Speed of mask conversion: |
One mask per 0.03s |
Program: |
2 sets programs, each program contains up to 30 steps |
Light source: |
Cool lights |
Auto-off function: |
After 10 minutes idle time. |
Power source: |
AC 220V ,50Hz or 110V, 60Hz |
Power consumption: |
80W |
Accessories: |
Remote control, Polarized metal screen, halogen lamp, polarized glasses, fuses(2), batteries(2) |
|
